Food/Pharmaceutical & Coplasticizer
In food and pharmaceutical industries, raw material comes into factory usually in form of bag package or hopper truck. Raw material has to be unloaded, stored, screened, dosed, grinded and mixed before going into downstream process. Pneumatic conveying is widely used for linking process steps and makes the whole plant under automatic control.
Due to stringent hygienic requirement in food and pharmaceutical industries, processing equipment has to be easy to clean. For material like pignut, soybean and coffee bean, pneumatic conveying must be carefully calculated and designed, and optimized pipe routine should be used to reduce conveying velocity so as to avoid severe breakage rate.
Scheme Content
Sino - Auto? can provide complete solutions for your solid material handling in all stages in food and pharmaceutical processing. Optimal container unloading and small bag unloading technique is the best way for you to reduce cost and improve production efficiency. Lower product fragmentation and residue can be realized due to optimized pneumatic conveying. Quick disassemble design and modular design of processing equipment enable system easy to meet stringent requirement of GMP. Automatic proportioning system has accurate precision and is open for customer to do on-line recipe management and provide an option of historic data retrieval and downloading.
Technical Advantages
-
01
Easy to clean and no residue
Quick disassemble and round design, no dead corner, inside / outside surface polishing Ra0.2 / Ra0.8
-
02
CIP cleaning
Stainless steel 316L, adequate design of drainage and drying, fulfill requirement of GMP
-
03
Automatic proportioning
Precision: major component 5‰, minor component 2‰
-
04
Degradation of material
Lower than 1‰ of material fragmentation can be reached via pneumatic conveying
-
05
Storage silo
Special design of silo can be provided for instance venting, nitrogen sealing and explosion pressure release
Scheme Value
Improve efficiency and save costs
Proprietary Automatic Unloading Technology for Containers and Bags
Reduction of breakage and residue of aggregates
Optimized pneumatic conveying system
Meet the requirements of clean production and GMP.
Design of Quick Disassembly Equipment and Modular Unit
Requirement for the accuracy of different main ingredients and accessories
Fully automatic batching system
Provides online recipe management and historical data query and download.
Related Cases
P&G North Carolina USA
Project：2010year，Stearate powder unloading and conveying
Materials：calcium carbonate powder, silica powder
Guangxi Forise Yeast
Project：2015year，Yeast conveying and mixing system
Materials： Yeast
Material properties：Particle size: Ф0.3x3mm; bulk density: 620kg / m3
Kraft Guangtong Food Ltd.
Project：2004year，Maxwell coffee 3 in 1 coffee conveying & mixing system
Materials：25 mesh sugar,coffee powder,NDC powder
Huzhou Mizuda Hope Bioscience
Project：2014year，6KT/Y Medicinal cellulose ether conveying system
Materials：cellulose powder, cellulose ether power
Material properties：Particle size: 200Mesh; bulk density: 150kg / m3
